Epc 2 d epc 2 d control epc 2 d control emergency panel ul 1008 transfer switch or equivalent emergency power source neutral not shown photo cell d wiring diagram 20a emergency panel or inverter emergency hot emergency light emergency neutral note. Pdf apprentice 3 panel wd0003 wiring diagrams.
Electrical And Automation Electrical Amp Automation Cadmatic
Epc 2 d wiring diagram. The epc 2 is ceiling or wall mounted in a junction box with a single gang plaster ring and is usually located in the area where the emergency fixtures are installed. Pdf wet location touch switch input module wd0401 wiring diagrams. No use model epc 2 d for 0 10v dimmers and epc d f ats for line voltage dimmers. Wiring diagrams visit our website. 2555 nicholson street san leandro ca 94577 4216 phone. A dedicated switch controls emergency lighting in a space.
This feature eliminates the need for manual monthly testing and is approved for this. Model description rating cepc 2 emergency power control 120v or 277v cepc 2 d 0 10v load emergency power control 120v 120v or 277v. To wiring diagram 2 should eliminate this issue contact mule for further assistance. Lsim p lsim r wts. Ap3 4 ap3 8 ap3 16 ap3 24 ap3 32. Upon loss of normal power the emergency lighting comes on regardless of switch position.
During normal operation the same switch occupancy sensor relay panel or lighting control switch regular and emergency lights on at full brightness regardless of switch position. Emergency light is also called ne light or normalemergency light by many speciers 6 blue. Wiring diagram ordering information additional resources epc 2 d installation sheet faq sheet alternative wiring sheet terms conditionswarranty information 20171010lvunv2 lvs inc. A dedicated dimmer controls emergency lighting in a space. Wiring diagram for 4 wire dimming loads cepc 2 d wiring ordering this is an accessory for eaton lighting control panels and greengate occupancy sensors. Pdf lightleeder rs232rs485 serial communications module wd1002.
When ordering specify the cepc as a separate accessory. How do i wire the epc 1 m d ats with daliecosystem loads. Patented automatic diagnostic when the room switch is turned off epc 2 d tests itself for 25 sec onds testing that an emergency power source is available and that the epc 2 d ballast and lamps are functioning correctly. Epc 1 d ats international dual field selectable auto test features 25sec monthly annual 120220230277v input. Wiring diagram ordering information additional resources epc 1 d installation sheet faq sheet alternative wiring sheet terms conditionswarranty information alternate model. Wiring diagram 2 shunt.
Please check this link.
