33 set the battery feed switch to the off position for page port access on the v2006a. The valcom v 2000a is an integrated single zone page control unit and provides telephone access to a single zone.
Teledynamics Product Details Vc V 9970
Valcom v 2003a wiring diagram. 1 2 3 or 5 6 7 for individual zones 1 through 3 respectively. Block diagram or loop start trunk port andor single line. Paging amplifier wiring diagrams. V 2003a supplies 1amp filtered 20 v 2006a supplies 15 amp filtered 30 v 2924av 2925a a. Collection of valcom paging horn wiring diagram. Valcom v 2003a wont work on either fxs or fxo mode so a universal telephone interface uti like valcom v 9970 must be used.
The v 2003av 2003ahf will return dial tone if so optioned. 8x8 adapter v 9970 v 2003a. Valcom one way paging system designinformation general. It shows the elements of the circuit as streamlined shapes and also the power as well as signal connections in between the gadgets. Allows you to conduct emergency page override for priority messages. Each of these units provide one zone of one way paging.
Page 7 this warranty is in lieu of and excludes all other warranties expressed or implied and in no event shall valcom inc. If more than one page port is. V 2000a is equipped with a background music port and is voice activated music mute when it is initiated. A wiring diagram is a simplified standard photographic representation of an electric circuit. 4 connection of one way amplified speakers see figure 1 66 block diagram. Dial 4 or 8 for the all call of all zones.
710h x 1000w x 300d 1803cm x 2540cm x 762cm. The v 2003a provides telephone systems access to 3 zones of one way paging and has built in tones for steady warble and alert. Connect wiring from telephone systems dry contact closure to wbr and ow of the 66 block. Valcom one way paging guide valcom talkback paging guide. The v 2003av 2003ahf is not field repairable. Valcom v 1094b v 2000a or v 2001a control units may be used for page port access to valcom paging.
With dedicated single line sets simple go off hook. To configure valcom v 9970 check article valcom v 9970 overhead paging system configuration for 8x8 services. To connect valcom v 2003a to v 9970 please see diagram. V 2003a 3 zones with all call background. Dial desired zone code. On the 8301 web interface go to basic settings features and set the line out analog output level to 10dbm 600 ohm 0245 vrms.
Vsp v 2006a2006ahf issue 10 1 947207 v 2006a integrated six zone paging control unit. Line powered 0 v 1109rtva 60 ma 250 ma 6. The v 2006av 2006ahf provides external power of 30 power units 15 amps. Block diagram for loop start trunk port andor single line. Be liable for any anticipated profits consequential damages loss of time or other losses incurred by the buyer in connection with the purchase operation or use of the. Ringback tone if so optioned will be heard in the telephone receiver.
