Gv2 l rated at twice the nominal primary current of t1 q3. Xb4 b or xb5 a pushbuttons t1.
Motor Control Solutions
Atv212 wiring diagram. Validity note original instructions and information given in the present document have been written in english before. Basic wiring for the atv212 drive. 100 va transformer 220 v secondary 1 fault relay contacts for remote signalling of the drive status. Recommended wiring diagram 3 phase power supply a1. By default from the factory terminals f to p24 are the run forward and run permissive input. Schneider electric 27883 views.
S1a53832 092011 5 about the book at a glance document scope the purpose of this document is. Validity note this documentation is valid for the altivar 212 drive. Atv212 quick start s1a53825 atv212 installation manual s1a53832 atv212 modbus manual s1a53844 atv212 bacnet manual s1a53845 atv212 metasys n2 manual s1a53846 atv212 apogée fln p1 manual s1a53847 atv212 lonworks manual s1a53848 multi loader manual bbv48778 somove mobile manual s1a51444 atv212 other option manuals. Atv 212 drive km1contactor q1. Atv212 altivar 212 environment. Limited wiring details provided with the drive.
The minimum requirements to operate an atv212 drive are a run command and a speed reference. Programming an atv212 drive for 2 wire control via as speed reference schneider electric support duration. Atv212 quick start s1a53825 atv212 installation manual s1a53832 atv212 modbus manual s1a53844 atv212 bacnet manual s1a53845 atv212 metasys n2 manual s1a53846 atv212 apogée fln p1 manual s1a53847 atv212 lonworks manual s1a53848 multiloader manual bbv48778 somove mobile manual s1a51444 atv212 other option manuals. Download documents for altivar 212 hvacvariable speed drives for 075 to 75kw motors. Purchase atv212 and conduit kit for type 1 installation type 12ip54 hp kw a catalog number qty frame size catalog number qty catalog number c qty frame size 208240 vac three phase 1 075 46 atv212h075m3x 1 vw3a31814 2 15 75 atv212hu15m3x 1 vw3a31814 3 22 106 atv212hu22m3x 1 vw3a31814. S1a53832 032019 9 about the book at a glance s1a53832 032019 document scope the purpose of this document is.
Zto give you mechanical and electrical information related to the atv212 drive zto show you how to install and wire this drive. To give you mechanical and electrical information related to the altivar212 drive to show you how to install and wire this drive.
